Battery Equipment
Sealed Drying Room
Fully Sealed Structure、 Dynamic Pressure Control, Intelligent Valve Management
Service Hotline+49 69 2713769195
Fully Sealed Structure | Dynamic Pressure Control | Intelligent Valve Management
|
Advantages |
Sealed Energy-Saving Synergy：High-Sealed enclosure minimizes air replenishment needs, combined with dual-stage dehumidification, reducing total energy consumption by 50%‒70%.
Smart IoT Management：Siemens PLC + IoT remote monitoring tracks real-time dew point/pressure/energy data, enabling fault alerts and historical analytics.
Industrial Robustness：304 stainless steel construction with Class 1 airtightness, withstands frequent door operations and corrosive environments, ensuring≥10-year lifespan.
|
Airtightness Design |
Full-Sealed Structure:Laser-Welded stainless steel enclosure + flange airtight connections, dual O-ring/inflatable seals,leakage rate ≤5×10-4 /h.
Dynamic Positive Pressure Control:Real-Time pressure sensors maintain dry air supply (dew point ≤-60°C), blocking external moisture.
Smart Valve System:Equipped with Electric Airtight Valve + modulating valves automatically adjust openings and seal pipelines during downtime, reducing leakage risks.
|
Energy Efficiency |
1. Dual-Stage Dehumidification
Rapid Dehumidification: Rotary dehumidifier lowers dew point to -45°C in 30 minutes.
Steady-State Maintenance: Molecular sieve adsorption system reduces energy consumption by 90%, achieving yearly savings of ≥438,000 kWh.
2. Intelligent Frequency Modulation
Auto-Adjusts rotor speed and regeneration power based on dew point feedback, maximizing efficiency.
| Modular & Scalable Design | Key Applications |
|
Modular Assembly:
95% material reuse rate, 60% lower relocation/retrofit costs.
|
Solid-State Battery:
Solid-State battery electrolyte membranes (sulfide/oxide/polymer).
Dry-process electrode production, lithium metal anode fabrication (dew point ≤-50°C).
|
|
Flexible Integration:
Customizable dimensions, compatible with glove boxes and vacuum systems for cross-industry synergy (lithium battery/semiconductor).
|
Semiconductors:
Photoresist storage (humidity <20 ppm),wafer packaging (anti-oxidation).
|
|
Pharma & Chemicals:
High-Purity API drying (±3 ppm control), nanomaterial synthesis (inert gas protection).
|
